Bio Safety Cabinet Class Ii Type A2

Click To Scan

Bio Safety Cabinet Class II Type A2

Description

Biological Safety Cabinet Class-II Type-A2 designed to protect the Laboratory staff, environment and sensitive work processes in which biological agents are used. The safety cabinet offers a superior level of contamination protection based on two advanced HEPA filters. The Biosafety cabinet configuration is freestanding. The Working area is made of stainless steel 304 grade material. The Cabinet body is made of Galvanized steel with powder coated material. Spillage tray below working surface, stopcock for draining the tray. In order to ensure consistent and reliable down flow velocity across the supply HEPA filter over the life of the cabinet, the cabinet use a pressure sensor (rather than anemometer) to detect pressure drop across the supply filter, rather than in just one point across the down flow.In order to preserve safety to the user and the environment, exhaust blowers automate balancing of downflow and inflow/exhaust velocities.The Cabinet automatically reduce fan/blower motor speed to 30% when the front window sash is in closed position to ensure reduced energy consumption when the cabinet is not is use.

Technical Data

  • ISO 14644-1 class 3 air quality
  • Front window 10” sash opening
  • Incorporate HEPA filter of the class H14 EN 1822
  • Dual DC motors automatically adjust the airflow speed without the use of a damper to ensure continuous safe working conditions, even without maintenance adjustments
  • All interior and exterior parts painted or smooth to ensure no risk of cuts to users or maintenance personnel
  • Heat emissions at 25°C 0.2 KW
  • Microprocessor controller and large LED display for inflow and down flow air velocity and hours of operation
  • Power Supply: 220-240V, 50Hz AC power supply
  • Ventilation system exhaust 300CFM
  • Audio-visual alarm for HEPA filter failure, blower failure, airflow speed failure, incorrect window position
  • Front of the cabinet angled 10° to help minimize glare on the window to the user for enhanced comfort and reduced operator fatigue
  • Provision for fitting taps for vacuum, water and non-combustible gas
  • In order to provide maximum effectiveness, efficiency and safety to laboratory personnel, UV light programmable to allow for specific exposure times from 30 minutes to 24 hours
  • Castors levelling jacks and locking facility
  • Microprocessor controller and same located on a slanted front panel so it is easy to see and reach from a seated working position in front of the cabinet
  • Microprocessor display the airflow velocities in real-time on an LED display to ensure the user knows whether or not the cabinet is working under safe operating conditions
  • Interior of the front window accessible for cleaning without requiring the user remove or support the window
Specs/Model MBMSJ-1018A-3 MBMSJ-1018A-4 MBMSJ-1018A-6
External Size (WxDxH)
1030x800x1500mm
1300x800x1500mm
1900x800x1500mm
Internal Size (WxDxH)
910x500x750mm
1200x500x750mm
1900x800x1500mm
Air Flow Volume (Inflow)
350 CFM
350 CFM
350 CFM
Air Flow Volume (Downflow)
225 CFM
225 CFM
225 CFM
Air Flow Volume (Exhaust)
350 CFM
350 CFM
350 CFM
Average Down flow Velocity
60FPM
60FPM
60FPM
Average Inflow Velocity
100FPM
100FPM
100FPM
Airflow Pattern
70% re-circulation, 30% air exhaust
Front sash
5mm clear toughened sliding front door
Supply/Exhaust Filter
HEPA Filter efficiency 99.995% at 0.3µm
Noise Level
60 dB(A)
Fluorescent light
1200 Lux
UV lamp
254 nm
Power Sockets
2 Nos. (15A/5A) Indian grade sockets inside the chamber

Additional Accessories

  • 5KVA Voltage Stabilizer
  • Adjustable Height Stand
  • UV Lamp
  • One set of detachable arms rest
