Bio Safety Cabinet Class II Type A2

Click To Scan

Bio Safety Cabinet Class II Type A2

Description

Biological Safety Cabinet Class-II Type-A2 designed to protect the Laboratory staff, environment and sensitive work processes in which biological agents are used. The safety cabinet offers a superior level of contamination protection based on two advanced HEPA filters. The Biosafety cabinet configuration is freestanding. The Interior work area made of a single piece of stainless steel 304 and single piece stainless steel work surface. Exterior is made of epoxy-coated steel material. Two pressure sensors which detect pressure changes across the exhaust and downflow plenums. Cabinet have a color touchscreen Graphical User Interface (GUI) and display the downflow air velocity and the inflow air velocity in real-time, to ensure the user knows whether the cabinet is working under safe operating conditions

Features

  • Dual long life ULPA/ HEPA (H-14 grade) filters for supply and exhaust airflow
  • Dual DC blower with auto-adjustment
  • LED bulb for chamber illumination
  • High performance motor to maintain air flow velocity
  • All wall of working chamber fully made of stainless steel 304 grade material
  • Front window with 10″ sash opening
  • Energy consumption of the cabinet 200W
  • Drain pan under the work tray made of stainless steel with angled sides
  • UV light programmable to allow for specific exposure times
  • 220-240V, 50Hz with single phase AC power supply
  • Protective window design
  • Dynamic chamber plenums with negative pressure surrounding without fabric bags
  • Frameless, shatterproof sash with automatic UV lamp automatic switch off when doors opened
  • Smooth surface for easy cleaning
  • HEPA filter zero-leak system
  • Microprocessor-based differential pressure sensor with real-time inflow & downflow display (LED/LCD/Touch)
  • Rolled steel plate with corrosion resistant epoxy resin powder sprayed on the surface which is resistant to acid and alkali corrosion
  • Raised airflow grille-side-capture zones and negative pressure side walls
  • Support stand with levelling bases, four universal casters for easy to move and lock levelling
  • Audio-visual alarms for airflow deviation/HEPA replacement, sound and light alarm function for abnormal parameters, sash open alarm at idle
  • One gas valve, one air valve, two duplex electrical outlets
  • Angled/slopped front to optimize user comfort reduce glare and maximize reach into the work area
Specs/Model MBMSJ-1018ANMD(I) MBMSJ-1018ANMD(II) MBMSJ-1018ANMD(III)
External Size (WxDxH)
1030x775x2295mm
1372x775x2295mm
1870x775x2295mm
Internal Size (WxDxH)
900x600x600mm
1200x600x600mm
1700x600x600mm
Air Flow Volume (Inflow)
350 CFM
35S0 CFM
350 CFM
Air Flow Volume (Downflow)
225 CFM
225 CFM
225 CFM
Air Flow Volume (Exhaust)
350 CFM
350 CFM
350 CFM
Down flow Velocity
0.35m/s, 70FPM
0.35m/s, 70FPMM
0.35m/s, 70FPM
Inflow Velocity
0.53m/s, 65FPM
0.53m/s, 65FPM
0.53m/s, 65FPM
Airflow Pattern
70% re-circulation, 30% air exhaust
Front sash
5mm clear toughened sliding front door
Supply/Exhaust Filter
HEPA/ULPA filter efficiency 99.999% at 0.1 to 0.3 micron
Noise Level
60 dB(A)
Fluorescent light
≥ 900Lux
UV germicidal lamp
254 nm

Additional Accessories

  • HEPA/ULPA filter
  • 5KVA Voltage Stabilizer
  • Magnehelic Gauge
  • Armrests
