Blood Bank Refrigerator MBMSJ-9010-01

Click To Scan

Blood Bank Refrigerator MBMSJ-9010-01

Description

Blood Bank Refrigerators are most versatile unit for Blood Bank specially designed for this purpose. It is available various capacity for storing 510 Nos. of blood bags of 350ml. Rotary air-cooling system allow homogenous distribution of clod air and ensures uniform temperature.

Blood Bank Refrigerators Interior is made of 0.8mm thickness of corrosion free stainless steel 304 grade material which helps in easy cleaning and exterior is made of 1mm 18swg CRCA Sheet with powder coated material. Blood Bank Refrigerators has triple pane glass door fitted in PUF insulated door which insulates the refrigerator from atmospheric temperature and better visibility of blood bags with key lock.

Technical Specifications

  • Temperature range 2°C to 6°C
  • Hotline around the mouth of cabinet to prevent moisture condensation
  • 80mm thickness of PUF insulation
  • 6 ”seven days ink-less pressure sensitive circular chart recorder and accuracy is ±1°C
  • Perforated sliding stainless steel tray which allows bags to be placed upright with sufficient airspace in between
  • Separate trays fitted with acrylic panel ensures minimal loss of cooling
  • LED bulb for uniform lighting and better visibility inside the cabinet
  • An alarm acknowledgement button
  • “On” indicator
  • Inbuilt microcontroller based temperature recorder and controller unit(TRCU) positioned at eye level for better visibility and monitor
  • 5 of stainless steel slide out trays
  • Chart change and chart set options in TRCU
  • Powder coated finish to guard against rust and corrosion
  • Refrigerator free of frost without elevating the chamber temperate
  • LED display segment with 5°C display resolution
  • Inbuilt internal stabilizer of 1KVA which ensures steady supply voltage for the whole blood storage cabinet and prevents voltage fluctuations
  • CFC free commercially refrigerant
  • Eye level indications of power/line in from inbuilt stabilizer
  • Two lockable casters in the front and two non-lockable casters in the rear
  • MCB protection in the input power line
  • Internal evaporator fan for uniform temperature maintenance inside the chamber and it switch off automatically whenever the door is opened
  • Temperature sensing method with encapsulated digital sensor dipped in 25% glycerin solution and kept in a plastic bottle
  • Data logging feature with removable data logger
  • Factory calibrated encapsulated digital sensor dipped in liquid medium to measure temperature at an accuracy of ±0.5°C
  • Negative temperature protection feature
  • User interface with membrane keypad
  • Inbuilt battery backup of (12V 3Ah), 2hr backup with rechargeable sealed maintenance free lead acid battery to ensure continuous operation of the TRCU during power

Alarms Indication

System OK Visual
Battery Low
Visual
Battery ON
Visual
Power Failure
Audio-Visual
Sensor Failure
Audio-Visual
Chart Change
Visual
Line In
Visual
Power
Visual
Compressor ON
Visual
Heater ON
Visual
Temperature High
Audio-Visual
Temperature Low
Audio-Visual
Door Open
Audio-Visual

Working environment

  • Temperature22°C to 33°C
  • Relativehumidity 10 to 90%
  • Atmosphericpressure 700 to 1060hpa

Storing and transportation

  • Temperature-20°C to 40°C
  • Relativehumidity 20to 90%
  • Atmosphericpressure 600 to 1060hpa

Power supply

The instrument is designed to operate on 220-240V, 50Hz Single Phase AC Supply  (Model with 110V also available)

Capacity (350ml Blood Bags)

  • 120Ltrs
  • 200Ltrs
  • 300Ltrs
  • 400Ltrs
  • 500Ltrs
  • 600Ltrs

Additional Accessories

  • VoltageStabilizer
