Semi-Automatic Cryosat MBMSJ-1006CS

Click To Scan

Semi-Automatic Cryosat MBMSJ-1006CS

Description

Semi-Automatic Cryostat microtome is designed for sectioning of natural tissue. These are specially designed for clinical and research operations. Sections have the high resolution of cytological details required for pathological diagnosis, histochemistry, fluorescence, biochemistry, microscopy etc. Technologies are simple and easy to learn.

Outer surfaces and controls of equipment coated with anti-microbial nano-silver coating to reduce risk of infection.

Features

  • Large Spacious Stainless steel cryo chamber
  • Easy-to-handle and stable clamping system for clamping the specimen discs
  • Section thickness selection from outside the cryochamber
  • Heated sliding glass door to prevent condensation
  • Microprocessor based touch screen operation
  • Heated removable sliding window
  • High performance routine with intuitive software and touch screen for simple efficient operation
  • Low-maintenance microtome with cross roller guides. Reproducible, high-quality thin sections by stepper motor specimen feed
  • Control panel with membrane-protected buttons and locking function
  • CFC-Free Eco-friendly & non toxic
  • Stable, self-contained cryo-cabinet on casters
  • LED display for cryochamber temperature, actual time, defrost time, and section thickness selection
  • UVC disinfection 30 and180 minutes cycles can be selected Disinfection can be aborted at any time if work needs to be resumed immediately
  • Visual indication of specimen stop positions (Front/Home)
  • Easy to clean, actively cooled specimen preparation zone with quick-freezing shelf for up to 8 specimens (min. temperature -40°C)
  • Automatic safety shut off of disinfection cycle when sliding window is opened
  • Easy-to-clean and disinfect
  • Self-explanatory symbols for all essential functions and displays
  • Spacious, stainless-steel cryochamber with antiglare LED illumination
  • Manual defrost cycle for chamber and quick-freezing shelf 12 minutes
  • Collection container for condensing water at front of instrument
  • Freestanding cryostat with encapsulated splash-proof rotary microtome
  • Handwheel capable to be locked in two positions
  • Cryochamber and quick-freezing shelf with integrated Peltier elements defrosted manually and equipped with an acoustic warning signal to prevent unintentional defrosting.

Modular Design Control System

  • Touch screen operation with intuitive software for multiple users
  • Hibernation automatically/manually, wake up in 15 minutes
  • Memory function for rapid advance and specimen positioning
  • Peltier cooling station for quick freezing of specimens
  • Section thickness totalizer with section counter
  • Slow & fast speeds of specimen feed forward & reverse

Microtome

  • Blade holder with finger guard to assure user safety
  • Illumination through bright white light with adjustable chamber brightness
  • 8° XY specimen orientation with zero-point reference
  • Specimen retraction 20μm can be switched off

Cryo Chamber

  • Cryochamber temperature selection from 0°C to -35°C adjustable in 1K increments at ambient temperature of 22°C
  • Heat Extractor in quick freeze shelf
  • Easy to clean actively cooled specimen preparation zone with quick- freezing shelf
  • Provision of integrated peltier fast freezing device

Disposable Blade Holder

  • Designed to use both High & low profile blades
  • An anti-fatigue cam lock ensures blades clamp tight
  • Lateral adjustment for blade holder
  • Anti-roll plates for better sectioning

Range of Trimming Thickness

  • 1 µm to 100 µm
  • 1 µm – 10 µm in increments of 1 µm
  • 10 µm – 20 µm in increments of 2 µm
  • 20 µm – 50 µm in increments of 5 µm
  • 50 µm – 100 µm in increments of 10 µm

Range of Section Thickness

  • 1 µm to 500 µm
  • 1 µm – 5 µm in increments of 0.5 µm
  • 5 µm – 20 µm in increments of 1 µm
  • 20 µm – 60 µm in increments of 5 µm
  • 60 µm – 500 µm in increments of 10 µm

Accessories

  • Large Spot Holders (13 Nos.)
  • Small Spot Holders (05 Nos.)

Technical specification

Number of Freezing Stations 8
Number of Peltier Cooled Freeze Stations
2 (17 K temperature difference to the quick-freezing shelf when the chamber temperature -35°C)
Motorized Coarse Feed
Two speeds: slow is max. 600μm/s and fast min. 900μm/s. Step function: 20μm each time the key is pressed at slow coarse feed speed
Total vertical specimen stroke
25mm
Total vertical specimen stroke
59mm
Maximum Specimen Size
55 x 80mm
Refrigeration Capacity
690W
Input Power
650 VA
Net weight
150Kg
Designed to Operate On
220V/50Hz AC Supply or 110V/60Hz AC Supply
Defrost
1 automatic defrost cycle per 24hr/manual(duration 12 minutes), Increment 15-minute
